HP ORANGE 3366 / PIGMENT ORANGE 13

Pigment Orange 13, pyrazolone orange, permanent orange G

P.O.13 is pyrazolone orange, comes in semitransparent types with specific surface areas between about 35 and 50 m2/g. P.O.13 is extensively used in the rubber industry, It is coloristically very similar to P.O.34, but generally somewhat yellower. The pigment blooms over a large concentration range and bleeds considerably. At concentrations below ca.0.1%, neither P.O.34 nor 13 are suited for use in rigid PVC.. P.O.13 shows less stability in paints than P.O.34 types of similar particle size. The graphics industry uses P.O.13 to an appreciable extent for packaging printing inks.

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button
HP ORANGE 3366

C.I.PO13
Chemical   Composition:
Color   Index: Pigment   Orange 13
C.I.NO.: 21110
Chemical Formula:          C32H24Cl2N8O2
CAS NO.:                   3520-72-7
EU NO.:                    222-530-3
Physical   Properties:
Physical   Form :             Orange   Powder
Heat Resistance(º C):           180
Density (g/cm3):       1.4
Specific Surface(m2/g): 40
PH Value:                  6.0-7.0
Oil Absorption(ml/100g):      40
Fastness   Properties:                       Full Color Tint Color
Dispersibility:              Excellent                     Excellent
Light Fastness:             6 4-5
Migration Resistance PVC 2

Features: low viscosity, high gloss, high color strength.

Application:

Recommended for :

plastics: EVA PVC, PE, PU

Printing inks: offset inks, water-based inks

pigments
