HP ORANGE 3136 / PIGMENT ORANGE 34

Pigment Orange 34 opaque type

Highly opaque versions of P.O.34 with coarse particle sizes and specific surface areas between ca. 15 and 25 m2/g, however, are gaining recognition within the paint field. Excellent flow properties make it possible to further increase the pigment level and the opacity, in which P.O.34 affords exceptionally good results for an organic pigment. Even at equal pigment concentration, P.O.34 is more opaque than commercially available Molybdate Red pigments which cover the same range of hues.

Full shades of this very opaque type are very fast to light and weather, and they have a much better ability to tolerate solvents and migration. This makes P.O.34 attractive as a partial or complete replacement for Molybdate Red in industrial finishes, tractor and agricultural implement finishes, house paints, etc. Its temperature stability is similarly superior. This is also true for application in print, where P.O.34 exhibits an increase in thermal stability from less than 120°C in transparent prints to 200°C in specialized opaque varieties

Quantity:
HP   ORANGE 3136

C.I.PO34



Chemical   Composition:
Color   Index:Pigment   Orange 34
C.I.NO.:21115
Chemical Formula:         C34H28Cl2N8O2
CAS NO.:                  15793-73-4
EU NO.:                   239-898-6



Physical   Properties:
Physical   Form :            Orange   Powder
Heat Resistance(º C):          180
Density (g/cm3):      1.6
Specific Surface(m2/g):48
PH Value:                 6.0-7.0
Oil Absorption(ml/100g):     55



Fastness   Properties:                      Full ColorTint Color
Dispersibility:             Excellent                    Excellent
Light Fastness:            76
Migration Resistance PVC4

Recommended Application

coatings: architectural coatings, coil coatings, industrial paints, powder coatings, printing pastes,

plastics: PVC, rubber, PP, PE, PU,

Printing inks: offset inks, water-based inks, solvent inks, UV inks.
