Product Description – PR202

HP RED 25215 (PIGMENT RED 202) is a highly weather-resistant and lightfast pigment and exhibits bluer and darker shades compared to PR122. It is primarily used in automotive coatings and plastic coloration. With high transparency and fine particle size, it delivers excellent rheological properties for metallic finishes. It is also suitable for packaging printing inks and wood coloring applications.

Recommended Application：

Coatings: solvent based coatings, water based coatings, auto paints, industrial coatings, powder coatings, wood coatings, coil coatings
Plastics: PP, PE, PVC, PS/SAN, ABS, PET, PBT, PMMA, Rubber/TPV
Printing inks: solvent based inks, water based inks

Technical Data:

Product Information
Chemical Type	Quinacridone		CAS NO.	3089-17-6
C. I. Name	Pigment Red 202		EINECS / ELINCS NO.	221-424-4
C. I. Constitution No.	73907		Chemical Formula	$C_{20} H_{10} C l_{2} N_{2} O_{2}$

Technical Performance
	Full Shade	Tint
Weather Resistance	5	4~5	Heat Stability °C	300°C
Light Fastness	8	7~8

Physical Properties
Physical Form	Powder		Bleeding in Xylene	5
Specific Density (g/cm3):	1.61 ± 0.1		Bleeding in Methyl Ethyl Ketone	5
Specific Surface(㎡/g):	49		Bleeding in Ethyl Acetate	5
Oil Absorption	42 ± 10		Bleeding in Cellosolve	5
pH Value	3 ~ 7		Bleeding in Mineral Turpentine	5
Volatile Matter	1% max		Resistance to Acid	5
			Resistance to Alkali	5
Packaging
10kgs/bag 400kgs/Pallet

Storage			Shelf Life	5 years
Should be stored in cool, dry and ventilate place.

TRANSPORTATION
Avoid inversion, sunlight, moisture and crash. Avoid damage the package.

Light fastness: Light fastness rating is assessed on 1 to 8 Blue Wool scale where 1 = ‘Poor’ and 8 = ‘Excellent’.
Heat Stability : Heat stability values given indicate the maximum temperature at which the pigment can be stoved for 10 min. on the full shade and in reductions without undergoing any significant change in shade.
Oil absorption: The oil absorption is determined on the basis of EN ISO 787-5 and given in g linseed oil per 100 gm. pigment.
Solvent bleeding: The bleeding in solvents is tested using the powder grades and the visual rating given on 1 to 5 Grey scale
where 1 = ‘Heavy bleeding’ and 5 = ‘No bleeding”

Disclaimer – The information given in this data sheet is based on the present state of our knowledge & is intended as a general description of our products & their possible applications. Due to the multitude of formulations, production & application conditions, all the above mentioned data have to be adjusted to the circumstances of the processor. No liabilities, including those for patent rights, can be derived from this fact for individual cases. It cannot be ruled out that this product contains particles < 0.1 μm. Any user of this product is responsible for determining the suitability of Sudarshan’s products for its particular application & to ensure that any proprietary rights & existing laws & legislation are observed.
