Honor Pigments

PIGMENT BLUE 15:3/ HP BLUE 43145

PIGMENT BLUE 15:3/ HP BLUE 43145

C.I.NO.: PB15:3

Advantage:

Main Application Recommended: Plastics

描述

Product Description – PB15:3

HP BLUE 43145 (PIGMENT BLUE 15:3) is a phthalo pigments with greenish shade. It has outstanding properties for light fastness, weather fastness and acid alkali fastness. It is mainly used in plastics/ Masterbatch indsutries.

Recommended Application

Plastics: PP, PE, PVC, PS/SAN, ABS, PC, POM, PA, PET, PBT, PMMA, Rubber/TPV, SBC, TPO, TPU

Technical Data:

Product Information
Chemical Type Phthalocyanine CAS NO. 147-14-8
C. I. Name Pigment Blue 15:3 EINECS / ELINCS NO. 205-685-1
C. I. Constitution No. 74160 Chemical Formula C32H16CuN8
Technical Performance
Full Shade Tint
Weather Resistance 4-5 4 Heat Stability °C 280°C
Light Fastness 8 7
Physical Properties
Physical Form Powder Bleeding in Xylene 5
Specific Density (g/cm3): 1.60 ± 0.1 Bleeding in Methyl Ethyl Ketone 5
Specific Surface(㎡/g): 33 ~63 Bleeding in Ethyl Acetate 5
Oil Absorption 40-60 Bleeding in Cellosolve 5
pH Value 5.5-8.5 Bleeding in Mineral Turpentine 5
Volatile Matter 1% max Resistance to Acid 5
Resistance to Alkali 5
Packaging
25kgs/bag 400kgs or 500kgs/Pallet
Storage Shelf Life 5 years
Should be stored in cool, dry and ventilate place.
TRANSPORTATION
Avoid inversion, sunlight, moisture and crash. Avoid damage the package.
  • Light fastness: Light fastness rating is assessed on 1 to 8 Blue Wool scale where 1 = ‘Poor’ and 8 = ‘Excellent’.
  • Heat Stability : Heat stability values given indicate the maximum temperature at which the pigment can be stoved for 10 min. on the full shade and in reductions without undergoing any significant change in shade.
  • Oil absorption: The oil absorption is determined on the basis of EN ISO 787-5 and given in g linseed oil per 100 gm. pigment.
  • Solvent bleeding: The bleeding in solvents is tested using the powder grades and the visual rating given on 1 to 5 Grey scale
    where 1 = ‘Heavy bleeding’ and 5 = ‘No bleeding”

Disclaimer – The information given in this data sheet is based on the present state of our knowledge & is intended as a general description of our products & their possible applications. Due to the multitude of formulations, production & application conditions, all the above mentioned data have to be adjusted to the circumstances of the processor. No liabilities, including those for patent rights, can be derived from this fact for individual cases. It cannot be ruled out that this product contains particles < 0.1 μm. Any user of this product is responsible for determining the suitability of Sudarshan’s products for its particular application & to ensure that any proprietary rights & existing laws & legislation are observed.
